DJI O4 Air Unit Pro
Key Specifications
Official DJI FPV air unit with DJI O4 video transmission, sold in two versions: O4 Air Unit Pro and O4 Wide Air Unit
O4 Air Unit Pro: 1/1.3 inch CMOS, 155° FOV, 4K/120fps video and 10 bit D Log M colour
O4 Wide Air Unit: 1/2 inch CMOS, ultra wide 159° FOV and 4K/60fps video at approx. 13.3 g
Max video transmission range up to 15 km (FCC) with the O4 Air Unit Pro
Racing mode with latency as low as 15 ms and up to 8 aircraft racing at once
1080p/100fps live view with H.265 encoding
RockSteady 3.0+ stabilization, stabilization off mode supports Gyroflow
O4 Air Unit Pro works with the DJI Avata 2 ND Filter Set and microSD cards up to 512 GB
Product Description
DJI O4 Air Unit Pro is an official DJI FPV air unit that brings O4 video transmission and a high quality camera to your own FPV drone. DJI sells it in two versions: the O4 Air Unit Pro, with a 1/1.3 inch sensor for 4K/120fps video and up to 15 km range for frames of 3 inches and above, and the O4 Wide Air Unit, a lightweight unit with a 1/2 inch sensor and a wider 159° FOV for beginners and FPV freestyle pilots.
New Heights in Transmission
The O4 Air Unit Series uses DJI O4 transmission with ultra low latency and automatic frequency selection. The dual antenna O4 Air Unit Pro reaches up to 15 km (FCC), while the single antenna O4 Wide Air Unit reaches up to 10 km.
Crisp and Fluid Live View
H.265 encoding delivers 1080p/100fps transmission for clear, smooth and real time imagery in your goggles.
New Racing Mode
Racing mode fixes recording and transmission at 1080p/100fps, lowers latency to as low as 15 ms with the O4 Air Unit Pro and DJI Goggles 3, and supports up to 8 aircraft racing at the same time, including alongside analog racing frequencies.
Upgraded Imaging
The O4 Air Unit Pro uses a 1/1.3 inch CMOS for 4K/120fps video with 10 bit D Log M colour. The O4 Wide Air Unit uses a 1/2 inch CMOS for 4K/60fps video, so no action camera is needed for ultra wide footage.
Ultra Wide FOV
The DJI O4 Wide Air Unit expands the FOV to 159° while keeping the lightweight design, HD image quality and O4 video transmission, for a more expansive and immersive flight perspective.
Even in Intense Light
The O4 Air Unit Pro works with the DJI Avata 2 ND Filter Set (ND8/16/32) for flexible control of light intake and shutter speed, achieving natural motion blur.
Canvas Mode and Betaflight OSD
Customize the real time data and layout shown in your goggles, so flight data is clear at a glance. Betaflight 4.3.0 and higher is supported.
Technical Specifications
Versions
DJI O4 Air Unit Pro; DJI O4 Wide Air Unit
Weight
O4 Air Unit Pro: approx. 32 g with camera module, 15.6 g without, antenna approx. 2.1 g each; O4 Wide Air Unit: approx. 13.3 g with camera module, 5.1 g without, antenna approx. 0.75 g
Transmission Module
O4 Air Unit Pro: 33.5×33.5×13 mm; O4 Wide Air Unit: 30×30×6 mm
Camera Module
O4 Air Unit Pro: 25.55×20×23.30 mm; O4 Wide Air Unit: 20.5×14×20.5 mm
Operating Frequency
5.170 to 5.250 GHz; 5.725 to 5.850 GHz
Max Video Transmission Range
O4 Air Unit Pro: 15 km (FCC), 8 km (CE), 8 km (SRRC); O4 Wide Air Unit: 10 km (IC), 6 km (CE), 6 km (SRRC) (with DJI Goggles 3 or Goggles N3)
Lowest Latency (1080p/100fps)
O4 Air Unit Pro: 15 ms with Goggles 3 and 19 ms with Goggles N3 in racing mode, under 30 ms with Goggles 2 or Goggles Integra; O4 Wide Air Unit: 20 ms with Goggles 3 and 24 ms with Goggles N3 in racing mode, 35 ms with Goggles 2 or Goggles Integra
Live View Quality
1080p at up to 100fps
Antenna
O4 Air Unit Pro: 2 antennas, 2T2R; O4 Wide Air Unit: 1 antenna, 1T1R
Image Sensor
O4 Air Unit Pro: 1/1.3 inch CMOS; O4 Wide Air Unit: 1/2 inch CMOS
Lens
O4 Air Unit Pro: FOV 155°, 12 mm equivalent, F2.8; O4 Wide Air Unit: FOV 159°, 16 mm equivalent, F2.8
ISO Range
O4 Air Unit Pro: 100 to 25600; O4 Wide Air Unit: 100 to 6400 (Auto), 100 to 12800 (Manual)
Max Video Resolution
O4 Air Unit Pro: 4K 3840×2160 at up to 120fps; O4 Wide Air Unit: 4K 3840×2160 at up to 60fps
Max Video Bitrate
O4 Air Unit Pro: 130 Mbps; O4 Wide Air Unit: 100 Mbps
Color Mode
O4 Air Unit Pro: Normal, D Log M; O4 Wide Air Unit: Normal
Stabilization
RockSteady 3.0+, stabilization off mode supports Gyroflow
Input Voltage
O4 Air Unit Pro: 7.4 to 26.4 V; O4 Wide Air Unit: 3.7 to 13.2 V
Storage
O4 Air Unit Pro: 4GB built in plus microSD up to 512 GB; O4 Wide Air Unit: 23GB built in
Operating Temperature
-10° to 40° C
Flight Controller
Betaflight 4.3.0 and higher
Compatibility
DJI Goggles 3, DJI Goggles N3 with DJI FPV Remote Controller 3; DJI Goggles 2, DJI Goggles Integra with DJI FPV Remote Controller 2
In the Box
DJI O4 Air Unit Pro: Camera Module × 1, Transmission Module × 1, Antenna × 2, 3 in 1 Cable × 1
DJI O4 Wide Air Unit: DJI O4 Wide Air Unit Camera Module × 1, DJI O4 Air Unit Transmission Module × 1, Antenna × 1, 3 in 1 Cable × 1
Available Configurations
DJI O4 Air Unit Pro
DJI O4 Wide Air Unit
Our team confirms the exact configuration with your order.
Frequently Asked Questions
Which goggles work with the DJI O4 Air Unit Pro?
DJI lists DJI Goggles 3 and Goggles N3 with the DJI FPV Remote Controller 3, and DJI Goggles 2 and Goggles Integra with the DJI FPV Remote Controller 2. Third party goggles are not supported.
What is the difference between the O4 Air Unit Pro and the O4 Wide Air Unit?
The O4 Air Unit Pro has a 1/1.3 inch sensor, 4K/120fps, D Log M, two antennas for up to 15 km range and a microSD slot, and suits frames of 3 inches and above. The O4 Wide Air Unit is much lighter (approx. 13.3 g) with a 1/2 inch sensor, 4K/60fps, a wider 159° FOV and 23GB built in storage.
Does it work with Betaflight?
Yes. It supports Betaflight 4.3.0 and higher, with Canvas Mode and Betaflight OSD settings. To use the DJI FPV Remote Controllers, the flight control protocol must be set to SBUS.
Can I race alongside analog video drones?
Yes. Racing mode fixes the video at 1080p/100fps, uses manual channel mode and is compatible with the race band frequencies used by analog video transmission.
